Comprehensive Microscope Solution Supplier for Biological and Industrial Inspection.
Wholesaletop Microscope Manufacturers for Dslr
Product details of the top microscope manufacturers
Product Information
The whole production process of HONYU top microscope manufacturers is under the strict supervision of professionals. Through the reform of details and materials of top microscope manufacturers, it is high performance with affordable price. Because of the high cost effectiveness, the product is more and more popular in the field.
Features
• 3.8x-230x magnification
• 5 step zoom objectives
• Separation Line Adjusting
Specification
|
Magnification |
3.8x~230x |
|
|
Head |
Binocular Head, 30° inclined, interpupillary distance 48~75mm, Diopter +/-5 adjustable |
|
|
With VIDEO port and PHOTO port |
||
|
Eyepiece |
WF10x/22mm, High Eyepoint |
|
|
WF20x/12mm, High Eyepoint |
||
|
Objective |
5 Step Zoom Plan Objective 0.8x, 1.25x, 2x, 3.2x, 4.8x |
|
|
Auxiliary Lens 0.4x, 2.0x |
||
|
Working Distance |
101mm |
|
|
View Field |
Diameter 2.3~62mm |
|
|
Magnification Correcting |
Magnification Correction System, with Correcting Lens |
|
|
Separation Line Adjusting |
Separation Line Adjust System in Back, with Special Designed Adjustment Driver |
|
|
Working Stage |
Square Manual Working Stage 90*90mm, Moving Range 54*54*54mm |
|
|
|
Round Titable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable |
|
|
|
Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm |
|
|
Bullet Holder |
Bullet Holder Set for all kinds of Bullet, Cartridge and other Objects |
|
|
Light Source |
12v 50w fan cooling strong halogen light, brightness adjustable (pair) |
|
|
5w led cold light, high brightness, brightness adjustable (pair) |
||
|
Coaxial Light Lens for observing in deep hole, or smooth object surface (Pair) |
||
|
Polarizing Light Lens, for eliminating flare lights and dazzling lights(Pair) |
||
|
Transmit bottom light |
||
|
Filters: red, green, uv |
||
|
Adapter |
Built-in 0.5x CCD Adapter |
|
|
Front View Photo Adapter for SLR Digital Camera |
||
|
Easy to view and take photos |
||
|
Power |
80~240v wide range voltage |
|
|
Dimension |
Instrument Size 37*30*63cm |
|
|
Packing case |
Aluminum Case Packing. Convenient for carrying and storing |
|
|
Optional accessories |
||
|
Light source |
150w cold light source, with optical fiber & light collector |
|
|
7" pad digital camera |
7 inch lcd pad digital camera, android system, |
|
|
9.7" pad digital camera |
9.7 inch lcd pad digital camera, android system, |
|
products display
Company Feature
• We own conductive conditions for material delivery. Nearby, there is a prosperous market, developed communication, and convenient transportation.
• HONYU becomes a leading company in the industry after years of wind and rain.
• In recent years, HONYU has continuously optimized the export environment and has striven to expanded export channels. Besides, we have actively opened up the foreign market to change the simplex situation of the sales market. All these contribute to the increment of market share in the international market.
All Biological Microscope,Stereo Microscope,Metallurgical Microscope,Operation Microscope,Comparison Microscope,Handheld Digital Microscope,Microscope Accessories are directly supplied by the factory. We provide discounts for a limit time. If you are interested, please contact HONYU as soon as possible.
HONYU is a professional optical supplier in China with more than 20 years’ experience in Microscopes.
