Eyepiece

High Eye-point Wide Field Plan Eyepiece PL10X/22mm

●

High Eye-point Wide Field Plan Eyepiece PL10X/22mm,with reticle

Optional

High Eye-point Wide Field Plan Eyepiece PL10X/22mm，Diopter adjustable

Optional

High Eye-point Wide Field Plan Eyepiece PL15X/16mm

Optional

Head

Compensation Trinocular Head

●

30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm, Light spliting ratio: 100:0 or 50:50 ,Diopter +/-5 Adjustable.

Compensation Binocular Head

Optional

30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm,,Diopter +/-5 Adjustable.

Objective

LWD Infinity Plan Achromatic Metallurgical Objectives 5X LMPL5X/0.15 WD10.8MM

●

LWD Infinity Plan Achromatic Metallurgical Objectives 10X LMPL10X/0.3 WD10MM

●

LWD Infinity Plan Achromatic Metallurgical Objectives 20X LMPL20X/0.45 WD4MM

●

LWD Infinity Plan Achromatic Metallurgical Objectives 50X LMPL50X/0.55 WD7.9MM

●

LWD Infinity Plan Achromatic Metallurgical Objectives 100X LMPL100X/0.8 WD2.1MM

Optional

Nosepiece

Back-Forward, 5 Holes Revolving Nosepiece, Inward

●

Stage

For Transmit & Reflect Light,

●

--Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment With Glass Plate,

--Coase Moving range:28mm; Max Sample height:28mm, Division:0.002mm

--with Tension adjustment loc,Top limit Kit.

For Reflect Light,

--Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment

Optional

With Metal Plate

--Coase Moving range:28mm; Max Sample height: 78mm, Division:0.002mm

Light Source

Reflected Light, Lamp House With Single 5W LED, Warm Color, Koehler Illuminator WIth Oblique Light Device, Center Adjustable Field And Aperture Diaphragm ,

●

Universal Voltage: 100-240V

Transmitted Light, Lamp House With Single 5W LED, Warm Color

●

Universal Voltage: 100-240V

Condenser

N.A. 0.9 Swing-out Achromatic Condenser For Transmit Light, With Center Adjustable Aperture Iris Diaphragm

●

Power Voltage

Wide Range Voltage 100~240V AC 50/60Hz

●

IF Filter

Blue IF Filter ,(for reflection):≤480nm

Optional

Green IF Filter ,(for reflection):520-570nm

Optional

Red IF Filter ,(for reflection):630-750nm

Optional

Natural IF Filter, ,(for reflection)

Optional

Filter

Yellow Filter（?45）

Optional

Green Filter（?45）

Optional

Blue Filter（?45）

Optional

Naturel Filter（?45）

Optional

Polarizing kits

30 Polarizer for reflection)

Optional

40 Polarizer (for transmitted)

Optional

360° Rrotatable,Can Be Out Of Light Path.

Optional

CCD Adapter

1XCCD adapter ,adjustable

Optional

2/3CCD adapter, adjustable

Optional

1/2C CCD adapter, adjustable

Optional
