Comprehensive Microscope Solution Supplier for Biological and Industrial Inspection.
Ophthalmic Surgical Microscope Manufacturers for Dslr on Sale
Product details of the ophthalmic surgical microscope manufacturers
Product Description
HONYU ophthalmic surgical microscope manufacturers aligns with SOP (Standard Operating Procedure) in production process. To ensure product quality, products are produced under the supervision of our experienced quality assurance team. The product has high customer satisfaction and shows a wider market potential.
Features
• Five Wide-field magnification settings: 50X to 500X
• Long working distance plan achromatic objectives
• Equipped with analyzer and polarizer
Specification
|
Eyepiece |
High Eye-point Wide Field Plan Eyepiece PL10X/22mm |
● |
|
High Eye-point Wide Field Plan Eyepiece PL10X/22mm,with reticle |
Optional |
|
|
High Eye-point Wide Field Plan Eyepiece PL10X/22mm，Diopter adjustable |
Optional |
|
|
High Eye-point Wide Field Plan Eyepiece PL15X/16mm |
Optional |
|
|
Head |
Compensation Trinocular Head |
● |
|
30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm, Light spliting ratio: 100:0 or 50:50 ,Diopter +/-5 Adjustable. |
|
|
|
Compensation Binocular Head |
Optional |
|
|
30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm,,Diopter +/-5 Adjustable. |
|
|
|
Objective |
LWD Infinity Plan Achromatic Metallurgical Objectives 5X LMPL5X/0.15 WD10.8MM |
● |
|
LWD Infinity Plan Achromatic Metallurgical Objectives 10X LMPL10X/0.3 WD10MM |
● |
|
|
LWD Infinity Plan Achromatic Metallurgical Objectives 20X LMPL20X/0.45 WD4MM |
● |
|
|
LWD Infinity Plan Achromatic Metallurgical Objectives 50X LMPL50X/0.55 WD7.9MM |
● |
|
|
LWD Infinity Plan Achromatic Metallurgical Objectives 100X LMPL100X/0.8 WD2.1MM |
Optional |
|
|
Nosepiece |
Back-Forward, 5 Holes Revolving Nosepiece, Inward |
● |
|
Stage |
For Transmit & Reflect Light, |
● |
|
--Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment With Glass Plate, |
|
|
|
--Coase Moving range:28mm; Max Sample height:28mm, Division:0.002mm |
|
|
|
--with Tension adjustment loc,Top limit Kit. |
|
|
|
For Reflect Light, |
|
|
|
--Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment |
Optional |
|
|
With Metal Plate |
|
|
|
--Coase Moving range:28mm; Max Sample height: 78mm, Division:0.002mm |
|
|
|
Light Source |
Reflected Light, Lamp House With Single 5W LED, Warm Color, Koehler Illuminator WIth Oblique Light Device, Center Adjustable Field And Aperture Diaphragm , |
● |
|
Universal Voltage: 100-240V |
|
|
|
Transmitted Light, Lamp House With Single 5W LED, Warm Color |
● |
|
|
Universal Voltage: 100-240V |
|
|
|
Condenser |
N.A. 0.9 Swing-out Achromatic Condenser For Transmit Light, With Center Adjustable Aperture Iris Diaphragm |
● |
|
Power Voltage |
Wide Range Voltage 100~240V AC 50/60Hz |
● |
|
IF Filter |
Blue IF Filter ,(for reflection):≤480nm |
Optional |
|
Green IF Filter ,(for reflection):520-570nm |
Optional |
|
|
Red IF Filter ,(for reflection):630-750nm |
Optional |
|
|
Natural IF Filter, ,(for reflection) |
Optional |
|
|
Filter |
Yellow Filter（?45） |
Optional |
|
Green Filter（?45） |
Optional |
|
|
Blue Filter（?45） |
Optional |
|
|
Naturel Filter（?45） |
Optional |
|
|
Polarizing kits |
30 Polarizer for reflection) |
Optional |
|
40 Polarizer (for transmitted) |
Optional |
|
|
360° Rrotatable,Can Be Out Of Light Path. |
Optional |
|
|
CCD Adapter |
1XCCD adapter ,adjustable |
Optional |
|
2/3CCD adapter, adjustable |
Optional |
|
|
1/2C CCD adapter, adjustable |
Optional |
products display
Company Feature
• HONYU enjoys traffic convenience due to the superior geographical conditions. We also have complete supporting facilities nearby.
• HONYU has built a high-quality talent team based on the principle of 'introduction' and 'training'. At present, we have a number of senior talents who are familiar with product production, enterprise management, and capital operation.
• The products of our company are favored by domestic and foreign customers.
As a powerful manufacturer, HONYU supplies Biological Microscope,Stereo Microscope,Metallurgical Microscope,Operation Microscope,Comparison Microscope,Handheld Digital Microscope,Microscope Accessories in various styles, models and functions in the long term. Please contact us to know more details.
HONYU is a professional optical supplier in China with more than 20 years’ experience in Microscopes.
