Product details of the operating microscope neurosurgery
Product Information
In terms of design style, HONYU operating microscope neurosurgery has been praised by experts in the industry, for its reasonable structure and appealing appearance. The quality inspection highly meets the international standards. The product shows dynamic in the market.
Features
• Five magnification levels: 2.7X, 4.4X, 6.6X, 10X, 16.6X
• Equipped with long working distance objective
• Brightness adjustable LED coaxial illumination
• Movable base bringing flexible examination
Specification
|
Observation angle |
45º tilted binocular observation unit |
|
Eyepiece |
16X |
|
Interpupillary distance |
50mm-80mm |
|
Diopter |
±5D |
|
Focal length of objective |
F=300mm(M58x0.75) |
|
Magnification changer |
5-step magnification change: 0.4X, 0.66X, 1X, 1.5X, 2.5X |
|
Total magnification |
2.7X, 4.4X, 6.6X, 10X, 16.6X |
|
Linear field |
90mm, 55mm, 37mm, 24mm, 15mm |
|
Beamsplitter |
50:50:00 |
|
CCD adapter |
For C-mount 1/3" cameras |
|
Fine focusing distance |
20mm |
|
Balance arm |
Counterweight adjustable |
|
Illumination system |
Coaxial illumination，brightness adjustable |
|
10W LED lamp |
|
|
Brightness |
>30000lux |
|
Filter |
Built-in Green and Blue |
|
Stand |
Short column fixed on the five-star base |
|
Optional accessories |
Demonstrator(assistant microscope), Camera (HDMI camera, VGA camera, USB camera), Photo adapter, LCD screen, Objective (F=230mm & F=280mm) |
Optical Parameter
|
Focal length of objective |
F=300mm |
F=230mm(optional) |
F=280mm(optional) |
|||||||||||||
|
Magnification on handwheel |
2.5x |
1.5x |
1x |
0.66x |
0.4x |
2.5x |
1.5x |
1x |
0.66x |
0.4x |
2.5x |
1.5x |
1x |
0.66x |
0.4x |
|
|
Total magnification |
16.6x |
10x |
6.6x |
4.4x |
2.7x |
21.7x |
13.2x |
8.7x |
5.7x |
3.5x |
17.8x |
10.8x |
7.1x |
4.7x |
2.9x |
|
|
Linear field (mm) |
15 |
24 |
37 |
55 |
90 |
11 |
18 |
28 |
42 |
62 |
14 |
22 |
35 |
54 |
84 |
|
|
Resolution (LP/mm) |
78 |
61 |
40 |
30 |
21 |
86 |
68 |
52 |
35 |
27 |
80 |
63 |
42 |
31 |
22 |
|
products display
