Comprehensive Microscope Solution Supplier for Biological and Industrial Inspection.
Oem & Odm Microscope Suppliers Microscope Suppliers Company
Company Advantages
· Our dedicated design team has greatly enhanced the appearance of HONYU microscope suppliers.
· Whatever products our microscope suppliers is used in, it works well.
· Right installation pack is guaranteed in HONYU to ensure the safety of microscope suppliers.
Features
• Five Wide-field magnification settings: 50X to 500X
• Long working distance plan achromatic objectives
• Equipped with analyzer and polarizer
Specification
|
Eyepiece |
High Eye-point Wide Field Plan Eyepiece PL10X/22mm |
● |
|
High Eye-point Wide Field Plan Eyepiece PL10X/22mm,with reticle |
Optional |
|
|
High Eye-point Wide Field Plan Eyepiece PL10X/22mm，Diopter adjustable |
Optional |
|
|
High Eye-point Wide Field Plan Eyepiece PL15X/16mm |
Optional |
|
|
Head |
Compensation Trinocular Head |
● |
|
30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm, Light spliting ratio: 100:0 or 50:50 ,Diopter +/-5 Adjustable. |
|
|
|
Compensation Binocular Head |
Optional |
|
|
30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm,,Diopter +/-5 Adjustable. |
|
|
|
Objective |
LWD Infinity Plan Achromatic Metallurgical Objectives 5X LMPL5X/0.15 WD10.8MM |
● |
|
LWD Infinity Plan Achromatic Metallurgical Objectives 10X LMPL10X/0.3 WD10MM |
● |
|
|
LWD Infinity Plan Achromatic Metallurgical Objectives 20X LMPL20X/0.45 WD4MM |
● |
|
|
LWD Infinity Plan Achromatic Metallurgical Objectives 50X LMPL50X/0.55 WD7.9MM |
● |
|
|
LWD Infinity Plan Achromatic Metallurgical Objectives 100X LMPL100X/0.8 WD2.1MM |
Optional |
|
|
Nosepiece |
Back-Forward, 5 Holes Revolving Nosepiece, Inward |
● |
|
Stage |
For Transmit & Reflect Light, |
● |
|
--Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment With Glass Plate, |
|
|
|
--Coase Moving range:28mm; Max Sample height:28mm, Division:0.002mm |
|
|
|
--with Tension adjustment loc,Top limit Kit. |
|
|
|
For Reflect Light, |
|
|
|
--Double Layer Mechanical Stage 175x145mm, Moving Range 76*42mm, X/Y Moving Coaxial Adjustment |
Optional |
|
|
With Metal Plate |
|
|
|
--Coase Moving range:28mm; Max Sample height: 78mm, Division:0.002mm |
|
|
|
Light Source |
Reflected Light, Lamp House With Single 5W LED, Warm Color, Koehler Illuminator WIth Oblique Light Device, Center Adjustable Field And Aperture Diaphragm , |
● |
|
Universal Voltage: 100-240V |
|
|
|
Transmitted Light, Lamp House With Single 5W LED, Warm Color |
● |
|
|
Universal Voltage: 100-240V |
|
|
|
Condenser |
N.A. 0.9 Swing-out Achromatic Condenser For Transmit Light, With Center Adjustable Aperture Iris Diaphragm |
● |
|
Power Voltage |
Wide Range Voltage 100~240V AC 50/60Hz |
● |
|
IF Filter |
Blue IF Filter ,(for reflection):≤480nm |
Optional |
|
Green IF Filter ,(for reflection):520-570nm |
Optional |
|
|
Red IF Filter ,(for reflection):630-750nm |
Optional |
|
|
Natural IF Filter, ,(for reflection) |
Optional |
|
|
Filter |
Yellow Filter（?45） |
Optional |
|
Green Filter（?45） |
Optional |
|
|
Blue Filter（?45） |
Optional |
|
|
Naturel Filter（?45） |
Optional |
|
|
Polarizing kits |
30 Polarizer for reflection) |
Optional |
|
40 Polarizer (for transmitted) |
Optional |
|
|
360° Rrotatable,Can Be Out Of Light Path. |
Optional |
|
|
CCD Adapter |
1XCCD adapter ,adjustable |
Optional |
|
2/3CCD adapter, adjustable |
Optional |
|
|
1/2C CCD adapter, adjustable |
Optional |
products display
Company Features
· With top-notch technology, HONYU provides the maximum-quality microscope suppliers.
· We carefully plan our production facilities to incorporate the latest technology and the most advanced machinery, tools, and equipment, so that we can manufacture the highest quality products possible. We have a robust sales teams to support our business. They possess in-depth knowledge of overseas markets, customer preferences, and market trends, enabling us to go global more easily. We have established a professional team. They are equipped with expertise in the microscope suppliers industry, offering creative process optimizations between us and our customers.
· Upholding the corporate philosophy “Dedicated to Customer Success,” we make united efforts to create innovative products that are globally competitive.
Product Comparison
HONYU's microscope suppliers is produced in strict accordance with standards. We make ensure that the products have more advantages over similar products in the following aspects.
Enterprise Advantages
HONYU has an elite team with rich industry experience. The team members are professional in scientific research, technology, operation, sales, and services.
We respect the value of consumer demand, and promote appropriate, reasonable, comfortable and positive service methods to provide more intimate services.
As a company with social responsibility, HONYU has always adhered to the enterprise spirit of 'concentration, dedication, and professionalism'. We pay great attention to the reputation, customers, and integrity during business development. We constantly innovate and pursue excellence, with the commitment of becoming a modern enterprise with a good reputation in the domestic market.
Founded in our company has been producing and processing products for years.
Our sale market covers the whole country. Our products are also exported to Southeast Asia, Africa and other countries and regions.
HONYU is a professional optical supplier in China with more than 20 years’ experience in Microscopes.
