Features
• Four Wide-field magnification settings: 40X, 100X, 400X, 1000X
• High contrast optics offers high resolution observations
• Equipped with N.A. 1.25 Abbe Condenser
• CE Approved and Manufactured Under ISO 9001 Quality Control Standard
Specification
|
Optical system |
Color corrected infinity optical system |
|
Head |
Compensation free binocular head, 30° inclined |
|
Eyepiece |
High Eye-point wide field PL10X/18mm |
|
Objective |
High contrast achromatic objective 4X |
|
High contrast achromatic objective 10X |
|
|
High contrast achromatic objective 40X (spring) |
|
|
High contrast achromatic objective 100X(spring) |
|
|
Nosepiece |
Reversed quadruple nosepiece |
|
Condenser |
Abbe.N.A1.25 Condenser |
|
Illumination |
90V~240V power input, Illumination by 6V 20W halogen bulb, brightness adjustable |
|
Stage |
Mechanical stage with damping clip,150x140mm in size, traveling range: 76x50mm |
|
Focusing |
Low position coaxial coarse and fine focus system with tension adjustment, with up-limited. Coarse focus range: 28mm, division of fine focus: 0.002mm |
|
Filter |
Blue filter Φ 45mm |
Optional Accessories
|
Head |
Seidentopf trinocular, 30° inclined |
|
Seidentopf binocular, 30° inclined(infinity) |
|
|
Seidentopf trinocular, 30° inclined(infinity) |
|
|
Eyepiece |
High-eyepoint WF10X/18mm |
|
High-eyepoint WF10X/18mm with micrometer |
|
|
High-eyepoint WF10X/18mm with cross hair |
|
|
High-eyepoint WF15x/14mm |
|
|
High-eyepoint WF16x/13mm |
|
|
High-eyepoint large field PL10X/20mm |
|
|
Objective |
Plan achromatic objective 4X, 10X, 40X, 100X |
|
Infinity plan achromatic objective 4X, 10X,20X, 40X(spring), 100X(spring) |
|
|
Stage |
140X132mm double layer mechanical stage with damping clip, traveling range:76 x 50mm |
|
Nosepiece |
Reversed quadruple nosepiece |
|
Filter |
Green, Yellow, Neutral |
|
Dark Field Condenser |
Dark Field Condenser(Dry) N.A.0.9 |
|
Dark Field Condenser(Immersion）N.A.1.25 |
|
|
TV Adapter |
0.5X |
|
0.35X |
|
|
Photo Attachment |
135 photo adapter (PK adapter of MD adapter) |
|
3.2X photo eyepiece |
|
|
Digital Photo Attachment |
C-mount |
|
Photo eyepiece |
|
|
Condenser |
Kohler condenser system |
|
Illumination |
High brightness LED light |
