Microscope Reduction Lens Inquire Now
Product details of the microscope reduction lens
Product Introduction
The raw materials of HONYU microscope reduction lens are high quality and sourced from premium suppliers. The quality of the product is reliable as it is in compliance with industry standards. The product has a potential prospect and keeps track with the market development.
Features
• USB2.0 high speed digital camera with CMOS sensor
• Capable of recording real-time, high-definition videos and capturing 5.1MP still images
• Compatible with Windows XP/Vista/7/8, Mac OS X and Linux
• Capable of being attachable to any microscopes, telescopes, endoscopes with C-mount
Specification
|
Hardware Configuration |
||
|
Max. Resolution |
2592x1944 (5.1 Mega Pixels) |
|
|
Pixel Size |
2.2μm x 2.2μm |
|
|
Frame Size and Rate |
5fps@2592x1944, 18fps@1280x960, 60fps@640x480 |
|
|
Sensor Model |
APTINA MT9P001(Color) |
|
|
Sensor Size |
1/2.5 inch (5.7mm(H) x 4.28mm(V)) |
|
|
Sensitivity |
0.53 V/lux-sec |
|
|
DynamicRange |
66.5dB |
|
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
|
SN Ratio |
40.5dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Binning |
1x1, 2x2, 4x4 |
|
|
Exposure |
0.294ms~2000msms |
|
|
Color Rendering Technique |
Ultra FineTM Color Engine |
|
|
White Balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
|
Capture/Control API |
Native C/C++ SDK, DirectShow, Twain |
|
|
Capture Mode |
Still Picture and Video |
|
|
Software Environment |
||
|
Operating System |
Windows XP / Vista / 7 / 8 (32 & 64 Bit) |
|
|
OS X (MAC OS X) |
||
|
Linux (Kernel 2.6 or Above) |
||
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or Higher |
|
|
Memory:2GB or More |
||
|
USBPort:USB2.0 High-speed Port |
||
|
Operating Environment |
||
|
Operating Temperature |
-10~60℃ |
|
|
Storage Temperature |
-30~80℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
Over USB Port |
|
Optional Accessories
|
Order Number |
Specification Description |
|
ADA.17.FMA050 |
0.5x Fixed Adapter for Eyepiece Tube or Trinocular Tube(23.2mm) |
|
ADA.17.AMA050 |
0.5x Adjustable Adapter for Eyepiece Tube or Trinocular Tube(23.2mm) |
|
ADA.17.EDA30 |
23.2mm to 30mm Eyepiece Adapter |
|
ADA.17.EDA305 |
23.2mm to 30.50mm Eyepiece Adapter |
Camera Standard Packing List
• One USB 2.0 5.1MP Digital Camera
• One high-speed USB 2.0 Cable
• One CD with Driver and Software
