Comprehensive Microscope Solution Supplier for Biological and Industrial Inspection.
Hot Selling Stereo Microscope Light Source Order now for Dslr
Product details of the stereo microscope light source
Quick Overview
The material used for stereo microscope light source makes its life span longer than others with normal material. The product is examined by undergoing detailed tests to guarantee quality and functionality. Ningbo Haishu HONYU Opto-Electro Co., Ltd provides stable and high quality stereo microscope light source products.
Product Description
Our stereo microscope light source has the following advantages over peer products.
Features
• Lab quality 0.7x-4.5x zoom video inspection lens
• high resolution and high contrast images offered
• Multiple CCD adapters and objectives available
Specification
|
Zoom range |
0.7X-4.5X |
|
Zoom Ratio |
01:06.4 |
|
Zoom Body Diameter |
Body Diameter for matching focusing mount: 45mm |
|
Standard Working Distance |
86mm(1X objective in Standard set) |
|
CCD Adapter |
1x CCD adapter in standard Set |
Optical Parameter
|
Magnification |
Working distance |
Field of View |
Depth of Field |
Numerical aperture |
Resolution |
|
0.7X |
85.6 |
10.3x5.8mm |
2.04mm |
0.025mm |
0.014mm |
|
1.0X |
85.6 |
7.2x4.1mm |
1.21mm |
0.033mm |
0.010mm |
|
2.0X |
85.6 |
3.6x2.0mm |
0.38mm |
0.053mm |
0.006mm |
|
3.0X |
85.6 |
2.4x1.3mm |
0.20mm |
0.067mm |
0.005mm |
|
4.0X |
85.6 |
1.8x1.0mm |
0.13mm |
0.079mm |
0.004mm |
|
4.5X |
85.6 |
1.6x0.9mm |
0.09mm |
0.090mm |
0.004mm |
products display
Company Introduction
Ningbo Haishu HONYU Opto-Electro Co., Ltd is a professional manufacturer of Biological Microscope,Stereo Microscope,Metallurgical Microscope,Operation Microscope,Comparison Microscope,Handheld Digital Microscope,Microscope Accessories, located in Our company believes that all services are for customers and our motivation comes from customer's satisfaction. Besides, we create and share value together. Based on that, we are committed to promoting development for the industry. With the experienced R&D technical personnel and professional operation team, we always insist on innovation and R&D of products and pay attention to the improvement of product competitiveness. At the same time our operation elites open markets with firm belief and push us move forward steadily in the highly competitive market. With a focus on customers' potential needs, HONYU provides customers with one-stop solutions.
Customers who need our products are welcomed to contact us for consultation.
HONYU is a professional optical supplier in China with more than 20 years’ experience in Microscopes.
