Features
• 3.8x-230x magnification
• 5 step zoom objectives
• Separation Line Adjusting
Specification
|
Magnification |
3.8x~230x |
|
|
Head |
Binocular Head, 30° inclined, interpupillary distance 48~75mm, Diopter +/-5 adjustable |
|
|
With VIDEO port and PHOTO port |
||
|
Eyepiece |
WF10x/22mm, High Eyepoint |
|
|
WF20x/12mm, High Eyepoint |
||
|
Objective |
5 Step Zoom Plan Objective 0.8x, 1.25x, 2x, 3.2x, 4.8x |
|
|
Auxiliary Lens 0.4x, 2.0x |
||
|
Working Distance |
101mm |
|
|
View Field |
Diameter 2.3~62mm |
|
|
Magnification Correcting |
Magnification Correction System, with Correcting Lens |
|
|
Separation Line Adjusting |
Separation Line Adjust System in Back, with Special Designed Adjustment Driver |
|
|
Working Stage |
Square Manual Working Stage 90*90mm, Moving Range 54*54*54mm |
|
|
|
Round Titable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable |
|
|
|
Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm |
|
|
Bullet Holder |
Bullet Holder Set for all kinds of Bullet, Cartridge and other Objects |
|
|
Light Source |
12v 50w fan cooling strong halogen light, brightness adjustable (pair) |
|
|
5w led cold light, high brightness, brightness adjustable (pair) |
||
|
Coaxial Light Lens for observing in deep hole, or smooth object surface (Pair) |
||
|
Polarizing Light Lens, for eliminating flare lights and dazzling lights(Pair) |
||
|
Transmit bottom light |
||
|
Filters: red, green, uv |
||
|
Adapter |
Built-in 0.5x CCD Adapter |
|
|
Front View Photo Adapter for SLR Digital Camera |
||
|
Easy to view and take photos |
||
|
Power |
80~240v wide range voltage |
|
|
Dimension |
Instrument Size 37*30*63cm |
|
|
Packing case |
Aluminum Case Packing. Convenient for carrying and storing |
|
|
Optional accessories |
||
|
Light source |
150w cold light source, with optical fiber & light collector |
|
|
7" pad digital camera |
7 inch lcd pad digital camera, android system, |
|
|
9.7" pad digital camera |
9.7 inch lcd pad digital camera, android system, |
|
products display
Company Advantages
· The design of microscope factory is very innovative.
· microscope factory's performance advantages are well known by its customers.
· Ningbo Haishu HONYU Opto-Electro Co., Ltd provides satisfactory services for the customer's value needs.
Company Features
· Ningbo Haishu HONYU Opto-Electro Co., Ltd is considered as a company with abundant experience and innovative spirit. We have been devoted to upgrading microscope factory.
· Our factory has imported a series of advanced production facilities that can ensure constant and steady production. This means that thousands of products can be made in astonishingly short periods of time.
· We customize and design microscope factory according to the requirement of the customer. Contact!
Application of the Product
HONYU's microscope factory is available in a wide range of applications.
With rich manufacturing experience and strong production strength, HONYU is able to provide professional solutions according to customers' actual needs.
HONYU is a professional optical supplier in China with more than 20 years’ experience in Microscopes.
