Comprehensive Microscope Solution Supplier for Biological and Industrial Inspection.
Ent Operating Microscope Manufacturers for Dslr Customized
Company Advantages
· HONYU has established stable business relationship and service networks in many countries.
· This product is under the stringent observation of our quality controllers.
· Ningbo Haishu HONYU Opto-Electro Co., Ltd will continue to improve our marketing network and service network in the coming days.
Features
• 0.63X-8X super widefield zoom magnification power
• Large working distance
• Widefield Optics Offering Crisp Clear Stereo Images
Specification
|
Item |
Specification |
Z12T |
Z12 |
|
Optical System |
Infinite Parallel Galileo Zoom Optical System |
● |
● |
|
Viewing Head |
Tilting trinocular viewing head, 5-45 degree adjustable; binocular: trinocular= 100:0 or 0:100; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw |
● |
○ |
|
30 degree inclined trinocular head; fixed light distribution, binocular: trinocular=50: 50; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw |
○ |
● |
|
|
Eyepiece |
High eye-point wide field plan eyepiece PL10×/22mm, diopter adjustable |
● |
● |
|
High eye-point wide field plan eyepiece PL15×/16mm, diopter adjustable |
○ |
○ |
|
|
High eye-point wide field plan eyepiece PL20×/12mm, diopter adjustable |
○ |
○ |
|
|
Zoom Range |
Zoom range: 0.63X-8X, click stop for 0.63×, 0.8×, 1×, 1.25×, 1.6×, 2×, 2.5×, 3.2×, 4×, 5×, 6.3×, 8×, with built-in aperture diaphragm |
● |
● |
|
Objective |
Plan Apochromatic Objective 0.5×, W.D.: 70.5mm |
○ |
○ |
|
Plan Apochromatic Objective 1×, W.D.: 80mm |
● |
● |
|
|
Plan Apochromatic Objective 1.5×, W.D.: 31.1mm |
○ |
○ |
|
|
Plan Apochromatic Objective 2×, W.D.: 20mm |
○ |
○ |
|
|
Zoom Ratio |
01:12.5 |
● |
● |
|
Nosepiece |
Nosepiece for 2 objectives |
○ |
○ |
|
Focusing Unit |
Coarse and fine coaxial focus system, integrated body with focus holder, coarse range: 50mm, fine precision 0.002mm |
● |
● |
|
Coaxial Illumination |
Intermediate magnification 1.5x, with 1/4λ glass slide, can be rotated 360 degrees, 20W LED cold light source power box, with brightness adjustment knob, flexible dual optical fiber, length 1 meter |
○ |
○ |
|
Base |
Flat base, without light source, with Φ100mm black and white plate |
○ |
○ |
|
Plan base with transmitted illumination (work with external 5W LED fiber); built-in 360 degree rotatable mirror, location and angle adjustable |
● |
|
|
|
Ultra-thin base, multiple LEDs (total power 5W), base with color temperature display and brightness display (color temperature range: 3000-5600K) |
● |
||
|
Illumination |
5W LED light box (size: 270×100×130mm) with single fiber (500mm), color temperature 5000-5500K; operating voltage 100-240VAC/50-60Hz, output 12V |
● |
|
|
LED Ring light (200pcs LED lamps) |
○ |
○ |
|
|
Camera Adapter |
0.5×/0.65×/1× C-mount adapters |
○ |
○ |
|
Packing |
1set/carton, Net/Gross weight: 14/16kg, Carton size: 59×55×81cm |
● |
● |
products display
Company Features
· Ningbo Haishu HONYU Opto-Electro Co., Ltd owns a large independent factory to manufacture ent operating microscope manufacturers.
· By virtue of our strong technology, ent operating microscope manufacturers has won the wide recognition of customers. The high quality of ent operating microscope manufacturers has promoted HONYU to be at the leading position.
· Our company's commitment to reducing the carbon footprint is unwavering. We will work hard to reduce indirect greenhouse gas emissions through the reduction of electrical consumption.
Product Comparison
The ent operating microscope manufacturers mainly promoted by HONYU have been further improved in the past through the technical improvement, which is reflected in the following aspects.
HONYU is a professional optical supplier in China with more than 20 years’ experience in Microscopes.
