Electron Microscope Manufacturers High Quality
Product details of the electron microscope manufacturers
Quick Overview
The raw material of electron microscope manufacturers is environmentally. The product has passed all relative certificates of quality. Due to its good characteristics, the product has received warm reception and rapid sales in the market.
Product Description
Compared with other similar products, our electron microscope manufacturers has the following advantages.
Features
• Four Wide-field magnification settings: 40X, 100X, 400X, 1000X
• High contrast optics offers high resolution observations
• Equipped with N.A. 1.25 Abbe Condenser
• CE Approved and Manufactured Under ISO 9001 Quality Control Standard
Specification
|
Optical system |
Color corrected infinity optical system |
|
Head |
Compensation free binocular head, 30° inclined |
|
Eyepiece |
High Eye-point wide field PL10X/18mm |
|
Objective |
High contrast achromatic objective 4X |
|
High contrast achromatic objective 10X |
|
|
High contrast achromatic objective 40X (spring) |
|
|
High contrast achromatic objective 100X(spring) |
|
|
Nosepiece |
Reversed quadruple nosepiece |
|
Condenser |
Abbe.N.A1.25 Condenser |
|
Illumination |
90V~240V power input, Illumination by 6V 20W halogen bulb, brightness adjustable |
|
Stage |
Mechanical stage with damping clip,150x140mm in size, traveling range: 76x50mm |
|
Focusing |
Low position coaxial coarse and fine focus system with tension adjustment, with up-limited. Coarse focus range: 28mm, division of fine focus: 0.002mm |
|
Filter |
Blue filter Φ 45mm |
Optional Accessories
|
Head |
Seidentopf trinocular, 30° inclined |
|
Seidentopf binocular, 30° inclined(infinity) |
|
|
Seidentopf trinocular, 30° inclined(infinity) |
|
|
Eyepiece |
High-eyepoint WF10X/18mm |
|
High-eyepoint WF10X/18mm with micrometer |
|
|
High-eyepoint WF10X/18mm with cross hair |
|
|
High-eyepoint WF15x/14mm |
|
|
High-eyepoint WF16x/13mm |
|
|
High-eyepoint large field PL10X/20mm |
|
|
Objective |
Plan achromatic objective 4X, 10X, 40X, 100X |
|
Infinity plan achromatic objective 4X, 10X,20X, 40X(spring), 100X(spring) |
|
|
Stage |
140X132mm double layer mechanical stage with damping clip, traveling range:76 x 50mm |
|
Nosepiece |
Reversed quadruple nosepiece |
|
Filter |
Green, Yellow, Neutral |
|
Dark Field Condenser |
Dark Field Condenser(Dry) N.A.0.9 |
|
Dark Field Condenser(Immersion）N.A.1.25 |
|
|
TV Adapter |
0.5X |
|
0.35X |
|
|
Photo Attachment |
135 photo adapter (PK adapter of MD adapter) |
|
3.2X photo eyepiece |
|
|
Digital Photo Attachment |
C-mount |
|
Photo eyepiece |
|
|
Condenser |
Kohler condenser system |
|
Illumination |
High brightness LED light |
products display
Company Advantages
Ningbo Haishu HONYU Opto-Electro Co., Ltd is a globally competitive supplier and manufacturer of electron microscope manufacturers. We have a team of experienced professionals. With years of research, they are knowledgeable about industry trends and the critical issues impacting the manufacturing industry. Ningbo Haishu HONYU Opto-Electro Co., Ltd has affirmed its long-standing commitment of electron microscope manufacturers. Get an offer!
If you have any questions, feel free to consult us.
