Features
• 0.63X-8X super widefield zoom magnification power
• Large working distance
• Widefield Optics Offering Crisp Clear Stereo Images
Specification
|
Item |
Specification |
Z12T |
Z12 |
|
Optical System |
Infinite Parallel Galileo Zoom Optical System |
● |
● |
|
Viewing Head |
Tilting trinocular viewing head, 5-45 degree adjustable; binocular: trinocular= 100:0 or 0:100; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw |
● |
○ |
|
30 degree inclined trinocular head; fixed light distribution, binocular: trinocular=50: 50; interpupillary distance 50-76mm; fixed eyepiece tube with lock screw |
○ |
● |
|
|
Eyepiece |
High eye-point wide field plan eyepiece PL10×/22mm, diopter adjustable |
● |
● |
|
High eye-point wide field plan eyepiece PL15×/16mm, diopter adjustable |
○ |
○ |
|
|
High eye-point wide field plan eyepiece PL20×/12mm, diopter adjustable |
○ |
○ |
|
|
Zoom Range |
Zoom range: 0.63X-8X, click stop for 0.63×, 0.8×, 1×, 1.25×, 1.6×, 2×, 2.5×, 3.2×, 4×, 5×, 6.3×, 8×, with built-in aperture diaphragm |
● |
● |
|
Objective |
Plan Apochromatic Objective 0.5×, W.D.: 70.5mm |
○ |
○ |
|
Plan Apochromatic Objective 1×, W.D.: 80mm |
● |
● |
|
|
Plan Apochromatic Objective 1.5×, W.D.: 31.1mm |
○ |
○ |
|
|
Plan Apochromatic Objective 2×, W.D.: 20mm |
○ |
○ |
|
|
Zoom Ratio |
01:12.5 |
● |
● |
|
Nosepiece |
Nosepiece for 2 objectives |
○ |
○ |
|
Focusing Unit |
Coarse and fine coaxial focus system, integrated body with focus holder, coarse range: 50mm, fine precision 0.002mm |
● |
● |
|
Coaxial Illumination |
Intermediate magnification 1.5x, with 1/4λ glass slide, can be rotated 360 degrees, 20W LED cold light source power box, with brightness adjustment knob, flexible dual optical fiber, length 1 meter |
○ |
○ |
|
Base |
Flat base, without light source, with Φ100mm black and white plate |
○ |
○ |
|
Plan base with transmitted illumination (work with external 5W LED fiber); built-in 360 degree rotatable mirror, location and angle adjustable |
● |
|
|
|
Ultra-thin base, multiple LEDs (total power 5W), base with color temperature display and brightness display (color temperature range: 3000-5600K) |
● |
||
|
Illumination |
5W LED light box (size: 270×100×130mm) with single fiber (500mm), color temperature 5000-5500K; operating voltage 100-240VAC/50-60Hz, output 12V |
● |
|
|
LED Ring light (200pcs LED lamps) |
○ |
○ |
|
|
Camera Adapter |
0.5×/0.65×/1× C-mount adapters |
○ |
○ |
|
Packing |
1set/carton, Net/Gross weight: 14/16kg, Carton size: 59×55×81cm |
● |
● |
