Comprehensive Microscope Solution Supplier for Biological and Industrial Inspection.
Cheapest Student Microscope Manufacturer for Sale
Product details of the student microscope manufacturer
Quick Detail
The machines used for HONYU student microscope manufacturer is regularly maintained and upgraded. At the same time, it also guarantees the upgrade and maintaince of student microscope manufacturer. The student microscope manufacturer produced by our company is widely used. The product has brought many benefits to customers owing to the efficient sales network.
Product Introduction
The overall quality of student microscope manufacturer has been greatly improved through the optimization of the following details.
Features
• Five magnification levels: 2.7X, 4.4X, 6.6X, 10X, 16.6X
• Equipped with long working distance objective
• Brightness adjustable LED coaxial illumination
• Movable base bringing flexible examination
Specification
|
Observation angle |
45º tilted binocular observation unit |
|
Eyepiece |
16X |
|
Interpupillary distance |
50mm-80mm |
|
Diopter |
±5D |
|
Focal length of objective |
F=300mm(M58x0.75) |
|
Magnification changer |
5-step magnification change: 0.4X, 0.66X, 1X, 1.5X, 2.5X |
|
Total magnification |
2.7X, 4.4X, 6.6X, 10X, 16.6X |
|
Linear field |
90mm, 55mm, 37mm, 24mm, 15mm |
|
Beamsplitter |
50:50:00 |
|
CCD adapter |
For C-mount 1/3" cameras |
|
Fine focusing distance |
20mm |
|
Balance arm |
Counterweight adjustable |
|
Illumination system |
Coaxial illumination，brightness adjustable |
|
10W LED lamp |
|
|
Brightness |
>30000lux |
|
Filter |
Built-in Green and Blue |
|
Stand |
Short column fixed on the five-star base |
|
Optional accessories |
Demonstrator(assistant microscope), Camera (HDMI camera, VGA camera, USB camera), Photo adapter, LCD screen, Objective (F=230mm & F=280mm) |
Optical Parameter
|
Focal length of objective |
F=300mm |
F=230mm(optional) |
F=280mm(optional) |
|||||||||||||
|
Magnification on handwheel |
2.5x |
1.5x |
1x |
0.66x |
0.4x |
2.5x |
1.5x |
1x |
0.66x |
0.4x |
2.5x |
1.5x |
1x |
0.66x |
0.4x |
|
|
Total magnification |
16.6x |
10x |
6.6x |
4.4x |
2.7x |
21.7x |
13.2x |
8.7x |
5.7x |
3.5x |
17.8x |
10.8x |
7.1x |
4.7x |
2.9x |
|
|
Linear field (mm) |
15 |
24 |
37 |
55 |
90 |
11 |
18 |
28 |
42 |
62 |
14 |
22 |
35 |
54 |
84 |
|
|
Resolution (LP/mm) |
78 |
61 |
40 |
30 |
21 |
86 |
68 |
52 |
35 |
27 |
80 |
63 |
42 |
31 |
22 |
|
products display
Company Advantages
Ningbo Haishu HONYU Opto-Electro Co., Ltd runs a main business of Biological Microscope,Stereo Microscope,Metallurgical Microscope,Operation Microscope,Comparison Microscope,Handheld Digital Microscope,Microscope Accessories. Our business range is complete, including production, processing, sales and scientific research. HONYU has a unique quality management system for production management. At the same time, our large after-sales service team can improve the quality of the products by investigating the opinions and feedback of customers. For bulk purchase of the products, please contact us.
HONYU is a professional optical supplier in China with more than 20 years’ experience in Microscopes.
